Gigabyte P650SS - 650W 80+ Silver Power Supply
Gigabyte P650SS - 650W 80+ Silver Power Supply
SKU:GP-P650SS
- 100% Genuine Products
- Easy Returns and Refunds
- Shipped in 1-2 Days
Couldn't load pickup availability
Model: GP-P650SS
- 80 PLUS Silver certified (230V EU)
- Support Intel ATX 3.0 standard (compatible with ATX 3.1)
- 120mm Fluid Dynamic Bearing (FDB) Fan
- Flat cable design
- Powerful single +12V rail
- OVP/OPP/SCP/UVP/OCP/OTP protection
|
Product Specification |
|
|
Model |
GP-P650SS |
|
Type |
Intel Form Factor ATX 12V v3.0 (compatible with ATX 3.1) |
|
PFC |
Active PFC (>0.9 typical) |
|
Input Voltage |
155-240 Vac |
|
Input Current |
6.3A |
|
Input Frequency |
50-60 Hz |
|
Output Capacity |
650W |
|
Dimension |
150 x 140 x 86 mm |
|
Fan Type |
120mm Fluid Dynamic Bearing (FDB) fan |
|
80 PLUS |
Silver |
|
Efficiency |
90% at typical load (230V EU) |
|
MTBF |
>100,000 hours |
|
Protection |
OVP/OPP/SCP/UVP/OCP/OTP |
|
Power Good Signal |
100-150ms |
|
Hold Up Time |
>16ms |
|
Cable Type |
Flat, All black |
|
Connectors |
ATX/MB 20+4 Pin x 1 : 600mm*1 CPU/EPS 4+4 Pin x 2 : 650mm+120mm*1 PCI-e 6+2 Pin x 2 : 600mm*2 SATA x 3 + 4 Pin Peripheral x 1 : 500mm+120mm+120mm+120mm*1 SATA x 2 + 4 Pin Peripheral x 2 : 500mm+120mm+120mm+120mm*1 |
|
Warranty |
3 years |
