Cooler Master NCore 100 Max Bronze edition Cabinet with PSU & CPU Cooler Included

Cooler Master NCore 100 Max Bronze edition Cabinet with PSU & CPU Cooler Included

SKU:NR100-ZNNN85-SL0

Regular price Rs. 31,500.00
Regular price Rs. 49,999.00 Sale price Rs. 31,500.00
36% OFF Sold out
Taxes included. Shipping calculated at checkout.
  • 100% Genuine Products
  • Easy Returns and Refunds
  • Shipped in 1-2 Days

Model: NR100-ZNNN85-SL0

  • High-end ITX design - At a volume of 15.7 liters and with premium Cooler Master cooling and power solutions, the NCORE 100 MAX satisfies all your performance and space-saving needs.
  • Ultra small footprint - NCORE100 Max footprint is 212*155mm (3slots mode) , which is 15.3% smaller than Mac mini . perfect choice to save your desk space
  • Support for the latest GPUs - Includes support for high performance, triple-slot GPUs up to 337mm in length and 180mm in height, with included ATX3.0 power cables and a vertical mount design. The PCIe slot can be adjusted for even larger GPU up to 357mm length.
  • Extendable width - Extendable width from 155mm to 172mm allows for 3.9 GPU slot thick RTX 4090 compatibility or 3 slot width for a super-small form factor.
  • Premium aluminium paneling - An anodized aluminium shell makes the NCORE 100 MAX stand out as a desktop work of art.
  • Tailor-made power solution - Cooler Master’s V SFX Gold 850W ATX 3.0 PSU covers all your power needs and comes with custom length cables.
  • High performance cooling solution - A custom thick radiator 120mm AIO cooling solution works well with the latest i9 and R9 CPUs and features both AMD AM4 and Intel LG1700 sockets.
  • Tool-less technology - The fully tool-less opening mechanism allows you easily access to every part of the NCORE 100 MAX.
  • PCIe 4.0 cable Included - A specially tailored PCIe 4.0 cable enables extra easy installation.

Product Specification

Product Name

NCORE 100 MAX Bronze edition

Model Number

NR100-ZNNN85-SL0

Color

Bronze

Materials

Exterior: Steel, Plastic, Aluminum

Left Side Panel: Aluminum

Dimensions

 (L x W x H)

Incl. Protrusions: 155mm x 212mm x 481mm (Normal mode) / 172mm x 212mm x 481mm (Expansion mode)

Excl. Protrusions  155mm x 212mm x 457mm / 172mm x 212mm x 457mm

Volume (Liters Incl. Protrusions): 15.80L / 17.54L

Motherboard Support

ITX

Expansion Slots

3 x PCIe Slot mounting

Drive Bays

5.25“ ODD: N/A

3.5” HDD: N/A

2.5” SSD: 1

I/O Panel

USB Ports: USB 3.2 Gen1 Type A x 2, USB 3.2 Gen2 x 2 Type C x 1

Audio In / Out 3.5mm: Audio combo x 1

Included Riser Cable

240mm PCIe 4.0 x16 x 1

Included CPU Cooling Solution

120mm Radiator with 38mm thickness x 1 (Custom PWM fan

max.2400RPM )

Included Power Supply Unit

V SFX Gold 850W ATX3.0

Pre-installed Fan(s)

120mm SickleFlow PWM fan x1(max. 1800RPM)

Clearances

CPU Cooler: 48mm

Power Supply: 100mm

RAM: 48mm

Graphics Card:   337mm x 62mm x 180mm (Normal, 3.0 Slot thick)

                                357mm x 79mm x 180mm (Expansion, 3.9 Slot thick)

                                (Maximum space including GPU power connector)

Cable Routing

Behind MB Tray: 11mm

Dust Filters

Side panels

Power Supply Support

SFX

Warranty

2 years (Case), 2 years (Thermal Solution), 10 years (Power Delivery)
