Cooler Master NCore 100 Max Bronze edition Cabinet with PSU & CPU Cooler Included
Cooler Master NCore 100 Max Bronze edition Cabinet with PSU & CPU Cooler Included
SKU:NR100-ZNNN85-SL0
- 100% Genuine Products
- Easy Returns and Refunds
- Shipped in 1-2 Days
Couldn't load pickup availability
Model: NR100-ZNNN85-SL0
- High-end ITX design - At a volume of 15.7 liters and with premium Cooler Master cooling and power solutions, the NCORE 100 MAX satisfies all your performance and space-saving needs.
- Ultra small footprint - NCORE100 Max footprint is 212*155mm (3slots mode) , which is 15.3% smaller than Mac mini . perfect choice to save your desk space
- Support for the latest GPUs - Includes support for high performance, triple-slot GPUs up to 337mm in length and 180mm in height, with included ATX3.0 power cables and a vertical mount design. The PCIe slot can be adjusted for even larger GPU up to 357mm length.
- Extendable width - Extendable width from 155mm to 172mm allows for 3.9 GPU slot thick RTX 4090 compatibility or 3 slot width for a super-small form factor.
- Premium aluminium paneling - An anodized aluminium shell makes the NCORE 100 MAX stand out as a desktop work of art.
- Tailor-made power solution - Cooler Master’s V SFX Gold 850W ATX 3.0 PSU covers all your power needs and comes with custom length cables.
- High performance cooling solution - A custom thick radiator 120mm AIO cooling solution works well with the latest i9 and R9 CPUs and features both AMD AM4 and Intel LG1700 sockets.
- Tool-less technology - The fully tool-less opening mechanism allows you easily access to every part of the NCORE 100 MAX.
- PCIe 4.0 cable Included - A specially tailored PCIe 4.0 cable enables extra easy installation.
Product Specification |
|
Product Name |
NCORE 100 MAX Bronze edition |
Model Number |
|
Color |
Bronze |
Materials |
Exterior: Steel, Plastic, Aluminum Left Side Panel: Aluminum |
Dimensions (L x W x H) |
Incl. Protrusions: 155mm x 212mm x 481mm (Normal mode) / 172mm x 212mm x 481mm (Expansion mode) Excl. Protrusions 155mm x 212mm x 457mm / 172mm x 212mm x 457mm Volume (Liters Incl. Protrusions): 15.80L / 17.54L |
Motherboard Support |
ITX |
Expansion Slots |
3 x PCIe Slot mounting |
Drive Bays |
5.25“ ODD: N/A 3.5” HDD: N/A 2.5” SSD: 1 |
I/O Panel |
USB Ports: USB 3.2 Gen1 Type A x 2, USB 3.2 Gen2 x 2 Type C x 1 Audio In / Out 3.5mm: Audio combo x 1 |
Included Riser Cable |
240mm PCIe 4.0 x16 x 1 |
Included CPU Cooling Solution |
120mm Radiator with 38mm thickness x 1 (Custom PWM fan max.2400RPM ) |
Included Power Supply Unit |
V SFX Gold 850W ATX3.0 |
Pre-installed Fan(s) |
120mm SickleFlow PWM fan x1(max. 1800RPM) |
Clearances |
CPU Cooler: 48mm Power Supply: 100mm RAM: 48mm Graphics Card: 337mm x 62mm x 180mm (Normal, 3.0 Slot thick) 357mm x 79mm x 180mm (Expansion, 3.9 Slot thick) (Maximum space including GPU power connector) |
Cable Routing |
Behind MB Tray: 11mm |
Dust Filters |
Side panels |
Power Supply Support |
SFX |
Warranty |
2 years (Case), 2 years (Thermal Solution), 10 years (Power Delivery) |
